Bobcat L65 Compact Wheel Loader

  • Bobcat L65 Compact Wheel Loader
  • Bobcat L65 Compact Wheel Loader
  • Bobcat L65 Compact Wheel Loader
  • Bobcat L65 Compact Wheel Loader
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Compact Wheel Loader

  • Bobcat Tier 4, turbo-charged engine delivers powerful, high-torque performance, high efficiency and convenient service
  • Articulated steering for a tight-turning radius and high maneuverability
  • High bucket capacity (7/8 cubic yard) and 10.5-foot lift height
  • Full-color, 5-inch display panel
  • Seat-mounted joystick
With a high bucket capacity, high lift height, impressive maneuverability and swift travel speeds it’s hard to beat the material-handling capabilities of the Bobcat® L65 compact wheel loader. This durable compact wheel loader delivers the performance, versatility and premium comfort to power through tough jobs in tight spaces.
Specifications
Model
L65
Category Name
Skid Steer
Year
2025
Sale Type
New
Manufacturer
Bobcat
l65 key specifications
Horsepower
55 hp
Operating Weight
9944 lbs
Auxiliary Std Flow
19.9 gpm
Travel Speed - Low
4.9 mph
Width (over Tires)
69.7 in
Travel Speed - High
15.1 mph
Rated Operating Capacity With Forks (Straight)
3759 lbs
Rated Operating Capacity With Bucket (Straight)
3133 lbs
Rated Operating Capacity With Forks (Articulated)
3172 lbs
Rated Operating Capacity With Bucket (Articulated)
2618 lbs
engine
Horsepower
55 hp
Turbocharged Engine
performance
Operating Weight
9944 lbs
Bucket Capacities
0.86- 1.3 yd3
Travel Speed - Low
4.9 mph
Travel Speed - High
15.1 mph
Tipping Capacity With Forks (Straight)
4699 lbs
Tipping Capacity With Bucket (Straight)
6266 lbs
Tipping Capacity With Forks (Articulated)
3965 lbs
Tipping Capacity With Bucket (Articulated)
5236 lbs
Rated Operating Capacity With Forks (Straight)
3759 lbs
Rated Operating Capacity With Bucket (Straight)
3133 lbs
Rated Operating Capacity With Forks (Articulated)
3172 lbs
Rated Operating Capacity With Bucket (Articulated)
2618 lbs
capacities
Fuel Tank
20.8 gal
hydraulic system
Auxiliary Std Flow
19.9 gpm
dimensions
Tire Size
365/70 R18
Wheelbase
82.7 in
Wheel Tread
55.5 in
Rollback Angle
55 deg
Ground Clearance
11.3 in
Oscillation Angle
8 deg
Articulation Angle
40 deg
Width (over Tires)
69.7 in
Width (with Bucket)
74.8 in
Outside Turning Radius
169.2 in
Height With Operator Cab
97.4 in
Length Without Attachment
193.9 in
Dump Angle @ Maximum Height
45 deg
Inside Turning Radius W/bkt
78.7 in
Length With Standard Bucket
218 in
Outside Turning Radius W/forks
180.8 in
Height To Hinge Pin - Fully Raised
127 in
drive system
Drive Type
Two-speed hydrostatic with Advanced Attachment Control
