Bobcat S66 Skid-Steer Loader
Call for Price
Overview
Specifications
s66 key specifications
engine
performance
capacities
hydraulic system
dimensions
literature
Documents
Skid-Steer LoaderThe nimble S66 features a unique balance of maneuverability and power with impressive lifting and pushing power. You’ll reach new heights of productivity with unmatched comfort features, precise material handling capabilities, fast cycle times and easy attachment changes.
|
|
Model
S66
Category Name
Skid Steer
Year
2025
Sale Type
New
Manufacturer
Bobcat
Horsepower
74 hp
Joystick Control
Optional
Operating Weight
7154 lbs
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
Rated Operating Capacity (ISO)
2400 lbs
Horsepower
74 hp
Turbocharged Engine
Horsepower Management
Included with SJC Option
Tipping Load
4800 lbs
Travel Speed
7.4 mph
Operating Weight
7154 lbs
Travel Speed (2-speed Option)
11 mph
Rated Operating Capacity (ISO)
2400 lbs
Rated Operating Capacity 200 Lb. Counterweight
2550 lbs
Fuel Tank
28.3 gal
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
System Relief @ Quick Couplers
3500 psi
Hydraulic System Pressure (Standard And High Flow)
3500 psi
Width
67 in
Height
80.5 in
Length
135 in
Wheelbase
44.6 in
Turning Radius
80.1 in
Width (with Bucket)
68 in
Reach @ Maximum Height
34.2 in
Height With Operator Cab
80.5 in
Length Without Attachment
107 in
Height To Bucket Hinge Pin
120 in
Length With Standard Bucket
135 in
